Model # DCA2500YV, Non Water Heating Assist Dehumidifier
Non Water Heating Assist Dehumidifier
Item # DCA2500YV — Model # DCA2500YV, Non Water Heating Assist Dehumidifier
Air Cooled, non water heating assist dehumidifiers are used when there is a primary pool and spa water heating source such as a hot water boiler in place.Typical applications would include, but not be limited to, small pool surface area projects or in cold climates or both.
If you cannot find the product you need, please let us know what your requirements are by contacting us.
Available Model Configurations
DCA2500YV: Air Cooled
DCA2500YV-CT: Water Cooled
Standard Features
- Listed to UL 60335-2-40
- 3 Year Parts Warranty
- Single Refrigeration Circuit
- Single Scroll Compressor
- Powder Coated, Galvannealed Steel Cabinet
- Low Ambient Head Pressure Control
- Remote Condenser Ready
- Rifle Tube Refrigeration Coils
- TEFC High Efficiency Blower Motor
- Stainless Steel Condensate Drain Pan
- Standard Microprocessor Control System
- ElectroFin Coated Coils
Optional Features
- Right Side Return Air
- Horizontal Discharge (Not Field Convertible)
- Extended Surface Filters 2" & 4"
- Outdoor Make Up Air Flanged Opening ( Damper & Filter by Others)
- External Static Upgrade
- Water Cooled Condenser For Water Heating Or A/C
- Motorized Evaporator Bypass Damper
- Remote Ready Delete
- Defrost Timer Package
- Control Options
- Space Heating Options Available
- Other Options Available
CFM
2500
Compressor Type
Scroll
Drain Connection
1" Bar Drain
External Static Pressure
1.00" H2O
Filter (Quantity: 4)
16" x 20" x 1" Fiberglass
Hot Gas Outlet [O.D.] (up to 50')³
0.875 in
Liquid Inlet [O.D.] (up to 50')³
0.5 in
Moisture Removal @ 82°DB / 50% R.H.¹
23.2 LB/HR
Moisture Removal @ 82°DB / 60% R.H.¹
29.9 LB/HR
Nominal Tonnage
5.1
Refrigerant
R-454B (Factory Charged 25 lbs.)
Sensible Cooling @ 82°DB / 50% R.H.²
37.1 MBH
Sensible Cooling @ 82°DB / 60% R.H.²
32.8 MBH
Weight
700 LB
Note
Ratings are subject to change without notice
Footnotes
1 Reheat Mode assuming 1050 BTU/lb
2 Cooling Mode with Remote Condenser at 95 °F
3 Over 50 ft contact factory
Compressor @ 208/230-1-60
62300 BTU
30.1 RLA
170 LRA
Blower Motor @ 208/230-1-60
2.0 hp
8.5 FLA
Unit FLA @ 208/230-1-60
40.0
Maximum Fuse Size @ 208/230-1-60
70
Minimum Circuit Ampacity @ 208/230-1-60
47.5
Operating Power @ 208/230-1-60
6.14 kW
Compressor @ 208/230-3-60
62700 BTU
21.2 RLA
156.5 LRA
Blower Motor @ 208/230-3-60
2.0 hp
6.6 FLA
Unit FLA @ 208/230-3-60
29.2
Maximum Fuse Size @ 208/230-3-60
45
Minimum Circuit Ampacity @ 208/230-3-60
34.5
Operating Power @ 208/230-3-60
6.55 kW
Compressor @ 460-3-60
62700 BTU
9.1 RLA
74.8 LRA
Blower Motor @ 460-3-60
2.0 hp
2.9 FLA
Unit FLA @ 460-3-60
12.7
Maximum Fuse Size @ 460-3-60
20
Minimum Circuit Ampacity @ 460-3-60
15.0
Operating Power @ 460-3-60
6.31 kW
Compressor @ 575-3-60
62700 BTU
7.7 RLA
47.8 LRA
Blower Motor @ 575-3-60
2.0 hp
2.3 FLA
Unit FLA @ 575-3-60
10.6
Maximum Fuse Size @ 575-3-60
17.5
Minimum Circuit Ampacity @ 575-3-60
12.5
Operating Power @ 575-3-60
6.30 kW
